CYCLONE SEPARATOR
oVERVIEW
A Cyclone Separator is an industrial air pollution control device that removes dust, particulates, and solid contaminants from gas streams using centrifugal force. Unlike dust collectors, it has no filter media — making it durable, low-maintenance, and ideal for handling large volumes of coarse dust.
✅ Key Benefits
- Low Maintenance: No filters to replace; simple design with minimal wear.
- Cost-Effective: Economical solution for coarse dust removal.
- Energy Efficient: Operates with low pressure drop compared to other systems.
How it works
- Step 1:Air Inlet
- Dust-laden air enters tangentially at high speed.
- Step 2: Spiral Motion
- The gas stream spins inside the cylindrical body, creating a vortex.
- Step 3: Particle Separation
- Heavier particles are forced outward by centrifugal force and slide down into a collection hopper.
- Step 4:Clean Air Outlet
- Purified air rises through the center and exits at the top.
